LFQ-B Computer High-speed Slitting And Rewinding Machine


Name:LFQ-B Computer High-speed Slitting And Rewinding Machine
No:LFQ-B

Performance and Characteristics

This machine is suitable for slitting and cutting such various roll materials as BOPP,PET, CPP, CPE, PVC, aluminum foil and paper,etc.

And can slit edge,separate and slit material according to different requirements during production. The machine is a kind of vertical slitting and cutting machines,unwinding and rewinding can be in front of or at the back of the machine.Independent master control screen, more flexible and even easier for operation. Automaticerro-correction of unwinding, photo cell is suitable for tracking the edge and color of transparent material. Unwinding tension adopts magnetic powder brake control. Rewinding adopts magnetic powder clutch control. Automatic waste film blowing device. Automatic meter counting for length of running material and automatic stop working.

Main Technical Parameters

Model

LFQ-1100

LFQ-1300

Max.width Of Unwinding

1100mm

1300mm

Max.diameter Of Unwinding

φ600mm

φ600mm

Width Of Slitting

30mm

30mm

Maxdiameter Of Erwinding

φ400mm

φ400mm

Seppd

10-150m/min

10-150m/min

Total Power

4.5kw

4.5kw

Weight

1500kg

1800kg

Overall Dimension(LxWxH)

1100×1800×1400mm

1100×2000×1400mm
